Prism Sound TITAN – Ultimate Collection
Including $4000 of premium instruments, contemporary FX plugins, an award-winning music production focused DAW and an industry-leading mastering and edit suite.
TITAN
TRUE REFERENCE AUDIO INTERFACE WITH MDIO EXPANSION
Titan and Atlas are world class multi-track interfaces offering flexible expansion and unsurpassable sonic clarity. Using the latest generation of Prism Sounds trusted conversion, Titan is ideal for music and sound recording, multi-tracking, overdubbing, stem-based mastering, analogue summing and critical listening applications.
UNSURPASSED CLOCKING AND JITTER REJECTION
Prism Sounds history in developing test and measurement equipment for the audio industry has allowed our engineers to get a much deeper understanding of digital clocking and its associated issues.
DIGITAL MIXER WITH FLEXIBLE MONITORING
Titan has a powerful built-in digital mixer that can be configured to provide a multitude of ultra low latency feeds, Including foldback to performers, stereo and surround outputs.
MIC PREAMPS
The Titan boasts 4 ultra-clean, low-noise microphone preamps that perfectly compliment its transparent A/D conversion (with software controllable phantom power, -20dB pad and Overkiller limiter switches on each channel.)
FUTURE PROOF CONNECTIVITY
With a standard USB connection Atlas can connect to the widest range of computers today and for the foreseeable future. Add to this the option of ProTools HDX and Dante modules for the most flexible and professional solution.
MDIO
MULTI-CHANNEL I/O EXPANSION
Atlas & Titan support Prism Sound’s MDIO expansion cards, which provide alternative “host” connections. The “host” is usually a computer and the Atlas or Titan interface provides a means of connection between the host and the external analogue and digital audio I/O ports.
The MDIO expansion slot provides an alternative host connection. It does not necessarily disable the USB port, but in the case of the Pro Tools interface MDIO-PTHDX, the USB port is switched off when the Pro Tools interface is to be used.
FLEXIBLE I/O
Titan has a maximum capability of 18 concurrent input and output channels, offering 8 analogue recording channels, 8 monitoring outputs, stereo digital input and output on a phono connector plus concurrent optical digital I/O ports.
FUTURE PROOF CONNECTIVITY
With a standard USB connection Titan can connect to the widest range of computers today and for the foreseeable future. Add to this the option of ProTools HDX and Dante modules for the most flexible and professional solution.
MDIO
MULTI-CHANNEL I/O EXPANSION
In an ever changing world of I/O connectivity, the MDIO expansion slot allows your Prism Sound interface to remain relevant, increasing its lifespan and bring a much better return on your investment.
Both options allow you to stack multiple Titan or Atlas providing sample accurate phase locked audio between multiple units.
TECH SPECS
INPUTS
4 x combo connectors with XLR sockets for mic input and 6.3mm TRS jack sockets for line input (balanced or unbalanced)
1 x RCA
1 x TOSLINK for S/PDIF or ADAT Optical input
OUTPUTS
8 x 6.3mm TRS jack sockets (balanced or unbalanced)
1 x RCA
1 x TOSLINK for S/PDIF or ADAT Optical output
DIMENSIONS
1U 19inch rack mountable
(rubber feet and rack ears supplied)
Table top (inc feet): W: 440mm D: 290mm H: 50mm
Rack-mount (inc ears):
W: 483mm D: 290mm H: 44.5mm
POWER
90-250VAC, 50/60Hz internal power supply
IEC 6A connector
35W 0.5A(T) 20mm ceramic fus
Pro Tools and Pro Tools | HDX is a trademark of Avid, a division of Avid Technology Inc.
