Prism Sound Lyra 2 – Ultimate Collection
Including $4000 of premium instruments, contemporary FX plugins, an award-winning music production focused DAW and an industry-leading mastering and edit suite.
LYRA 2
ULTIMATE COLLECTION VERSION
The Prism Sound Ultimate Collection is an optional bundle of products offered when purchasing a LYRA 1, LYRA 2, or TITAN interface.
Gain access to a wealth of creative, innovative, and industry-leading audio tools. Prism Sounds Ultimate Collection is valued at over $4000, and features an array of premium instruments, contemporary FX plugins, an award-winning music production focused DAW and an industry-leading mastering and edit suite.
LYRA 2
REFERENCE GRADE COMPACT AUDIO INTERFACE
Lyra represents the pinnacle of compact audio interfaces. Packing Prism Sounds trusted, uncompromising AD/DA conversion into a compact chassis perfect for use in the studio or on the road.
Based on the Orpheus’ audio path and clock circuitry, Lyra is ideal for those who don’t require a large I/O count, but do demand the highest quality and most transparent AD/DA available.
RENOWNED AD/DA CONVERSION
Lyra cuts no corners in its design and boasts the same trusted Prism Sound convertors used on countless hit records. It’s ultra-transparent characteristic means what you put into the Lyra is exactly what you get out of it.
PRISTINE PRE-AMPLIFICATION
Featuring two class-A microphone preamps, Lyra 2 guarantees superbly clean, detailed recordings that capture a performance the way it was intended.
SOFT-CLIP LIMITING (OVERKILLER)
Lyra's analogue input channels include a switchable Prism Sound 'Overkiller' circuit. This soft-clip limiter gently absorbs transients and allows signal levels to be pushed to their limits without risk.
QUALITY SUPPORT
Prism Sound's reputation for audio excellence has been matched only by its top quality after-sales support and technical advice. The longevity of a Prism Sound product is a testament to the dedicated team behind it.
2 A/D Analogue Input Channels
4 D/A Analogue Line Output Channels
S/PDIF / ADAT Digital In/Out
ADAT (8 channel): 44k1, 48k
ADAT SMUX (4 channel): 88k2, 96k
AES3 Mode on RCA/Phono
Word-clock Sync I/O
| Formats supported: Lyra 2 | S/PDIF (RCA or TOSLINK), ADAT, ADAT S/MUX (TOSLINK), AES3 (XLR via supplied adapter cable) |
| Sample rates supported | 44.1, 48, 88.2, 96, 176.4 and 192kHz |
| Sample rates supported: ADAT (Lyra 2 only) |
ADAT (8 channel): 44k1, 48k ADAT SMUX (4 channel): 88k2, 96k |
| Channel Status: | Ignored |
| Word-length | 24 bit |
| AES3 Operation (Lyra 2) | Via S/PDIF RCA, using XLR-RCA adapter (supplied) |
| Sample-rate converter (SRC) | Selectable at S/PDIF input; allowing input at any sample rate |
| Bit transparency | Maintained (allows recording of Dolby or DTS streams) |
| Formats supported | S/PDIF (RCA or TOSLINK), ADAT, ADAT S/MUX (TOSLINK), AES3 (RCA) |
| Sample rates: S/PDIF/AES3 | 44.1, 48, 88.2, 96, 176.4 and 192kHz |
| Sample rates: ADAT (Lyra 2 only) |
ADAT (8 channel): 44k1, 48k; ADAT S/MUX (4 channel): 88k2, 96k |
| Channel Status | Full implementation, Consumer (S/PDIF) or professional (AES3) |
| Word-length | 24 bit, or reduction to 16 bits using flat TPDF dither or Prism Sound SNS (Super Noise Shaping – four alternative shapes available) |
| AES3 (AES/EBU) operation (Lyra 2 only) |
via S/PDIF RCA, using RCA-XLR adaptor (supplied) and AES3 mode (2V p-p, 110Ω and AES3 channel status) |
| Sample-rate converter (SRC) (Lyra 2 only) |
Selectable at S/PDIF output; output rate can be referenced to Wordclock, DI or local clock at 44.1, 48, 88.2, 96, 176.4 or 192kHz |
| Bit transparency | Maintained in 24 bit mode (allows playback of Dolby or DTS streams to external decoder) |
