Volt 476P er det perfekte USB-lydkortet for kreative samarbeidspartnere som enkelt vil ta opp større lydprosjekter med legendarisk studiolyd. Koble rett til Mac, PC, iPad eller iPhone og Volt dukker opp, klar til å skape noe fantastisk med profesjonell lyd fra Universal Audio.
Lag legendarisk klingende musikkproduksjoner, livestreams og podcaster på Mac, PC, iPad og iPhone
SYSTEM |
|
|
I/O Complement |
|
|
Microphone/Line/Instrument Preamp Inputs Volt 1 Volt 2 Volt 4 Volt 176 Volt 276 Volt 476 Volt 476P |
Combo XLR/TRS One Two Two One Two Two Four |
|
Line Outputs (Volt 4, 476 and 476P only) |
Four |
|
Monitor Outputs |
Two (one stereo pair) |
|
Headphone Outputs |
two stereo on Volt 476P |
|
USB |
One USB 2.0 port (USB Type-C connector) |
|
MIDI |
In, Out (two 5-pin DIN connectors) |
|
A/D – D/A Conversion |
|
|
Supported Sample Rates (kHz) |
44.1, 48, 88.2, 96, 176.4, 192 |
|
Bit Depth Per Sample |
24 |
ANALOG I/O |
|
|
Mic, Line, Instrument Input(s) |
|
|
Vintage mode (all Volt models) |
Selectable ON/OFF |
|
76 Compressor presets (476P only) |
Selectable VOC, GTR, FAST |
|
76 Compressor preset times VOC GTR FAST Compression Ratio |
Attack / Release times (approximate) Attack 2 ms / Release 300 ms Attack 1.5 ms / Release 700 ms Attack 30 µs / Release 35 ms 6:1 |
|
Microphone Input(s) |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.1 dB |
|
Dynamic Range (A–weighted) |
112 dB |
|
Total Harmonic Distortion + Noise |
-103 dB (0.0007 %) |
|
Equivalent Input Noise (150 Ohms, A-weighted) |
-127 dBu |
|
Maximum Input Level |
9 dBu |
|
Input Impedance |
3 Kilohms |
|
Available Gain |
55 dB |
|
Phantom Power |
+48V (switchable) |
|
Connector Type |
XLR Female, pin 2 positive |
|
Instrument Input(s) |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.05 dB |
|
Dynamic Range (A–weighted) |
111 dB |
|
Total Harmonic Distortion + Noise |
-84 dB (0.006 %) |
|
Maximum Input Level |
12.5 dBu |
|
Input Impedance |
1 Megohms |
|
Gain Range |
55 dB |
|
Connector Type |
¼” TS unbalanced |
|
Line Input(s) |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.05 dB |
|
Dynamic Range (A–weighted) |
111 dB |
|
Total Harmonic Distortion + Noise |
-102 dB (0.0008 %) |
|
Maximum Input Level |
22 dBu |
|
Input Impedance |
15 Kilohms |
|
Gain Range |
55 dB |
|
Connector Type |
¼” TRS balanced or TS unbalanced |
|
Line Inputs 3-4 (Volt 4, 476 only) |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.05 dB |
|
Dynamic Range (A–weighted) |
113 dB |
|
Total Harmonic Distortion + Noise |
-105 dB (0.0006 %) |
|
Maximum Input Level |
18 dBu |
|
Input Impedance |
10 Kilohms |
|
Connector Type |
¼” TRS balanced or TS unbalanced |
|
Monitor & Line Outputs |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.1 dB |
|
Dynamic Range (A–weighted) |
110 dB |
|
Total Harmonic Distortion + Noise |
-102.5 dB (0.00075%) |
|
Maximum Output Level |
15 dBu |
|
Output Impedance |
100 Ohms |
|
Connector Type |
¼” TRS balanced or TS unbalanced |
|
Stereo Headphone Outputs |
|
|
Frequency Response |
20 Hz to 20 kHz, ±0.1 dB |
|
Dynamic Range (100K load, A-weighted) |
110 dB |
|
Total Harmonic Distortion + Noise |
-100 dB (0.001%) |
|
Maximum Output Power into 32 Ohms Maximum Output Power into 300 Ohms Maximum Output Power into 600 Ohms |
84 mW per channel 22 mW per channel 12 mW per channel |
|
Connector Type |
¼” TRS Stereo |
ELECTRICAL |
|
|
External DC Power Input |
Barrel, female, 5.5mm OD, 2.1mm ID, |
|
Power Supply, Electrical Requirements |
+5VDC, Center Positive (+) |
|
Power Consumption Volt 476P |
10.6W maximum, 6.6W typical |
ENVIRONMENTAL |
|
|
Ambient Temperature Range |
32° to 104° F (0° to 40° C) |
MECHANICAL |
|
|
Dimensions |
|
|
Chassis (including knobs and protrusions) Volt 476P |
Width x Depth x Height 10.3 x 5.2 x 2.6 x in (26,2 x 13,2 x 6,6 cm) |
|
Shipping Box Volt 476P |
Width x Depth x Height 11.8 x 8.46 x 5.59 in (30,0 x 21,5 x 14,2 cm) |
|
Weight |
|
|
Shipping Weight (with box & accessories) Volt 1 Volt 2 Volt 4 Volt 176 Volt 276 Volt 476 Volt 476P |
1.9 lbs (0.9 kg) 2.2 lbs (1.0 kg) 2.7 lbs (1.2kg) 2.2 lbs (1.0 kg) 2.6 lbs (1.2 kg) 3.5 lbs (1.6 kg) 3.5 lbs (1.6 kg) |
|
Weight (bare unit) Volt 1 Volt 2 Volt 4 Volt 176 Volt 276 Volt 476 Volt 476P |
1.2 lbs (0.55 kg) 1.4 lbs (0.65 kg) 1.7 lbs (0.7 kg) 1.4 lbs (0.65 kg) 1.8 lbs (0.79 kg) 2.0 lbs (0.92 kg) 2.5 lbs (1.1 kg) |
|
Package Contents |
|
|
Volt Audio Interface Unit USB Type-A to Type-C cable USB Type-A to DC Barrel cable External Power Supply Unit with AC adapter kit (Volt 476, 476P only) |
|
