_PHOEBE
NG500 Class A preamplifier with digital recall
The most noble character of microphone preamplifiers now fully integrated with digital workflow. Dual amp vintage design with most demanded modern features! We are proud to present _PHOEBE – NG500 fully analog, Class A microphone/line/instrument preamplifier with digital recall.
Audio signal is processed only via analog components!
Main features summary:
· 100% analog microphone/line preamp with +28dBu of headroom.
-
· Class A fully analog - inspired by famous 1073 design based on
dual amp topology.
-
· Microphone gain up to 75dB.
-
· Carnhill Transformers (input and output).
-
· Output signal metering on the front panel with clip detection.
-
· Phantom power and phase invert control.
-
· Switchable impedance input (1200/300Ohm).
-
· All controls/analog settings are fully manageable via the
WesAudio GCon DAW plug-in.
-
· IRON PAD - passive output attenuation circuit with 1 dB step
(after the output transformer).
-
· Front panel XLR/TRS socket which supports - HiZ instrument input
(TRS), line input (XLR), microphone input (XLR).
-
· Recallable signal source to be either back XLR Socket, or front panel
XLR/TRS socket.
-
· 500 series and ng500 (e.g. _TITAN) series compatible.
-
· Total Recall and plugin control compatible with most DAWs.
-
· Analog automation in DAW.
Other features:
· Fully digitally controlled and isolated analog circuit.
· Digital recall can be achieved by connecting the unit directly through the front panel mini USB socket,or using it inside _TITAN chassis.
· Free software and firmware upgrades.
Specs:
· Line input impedance: 5.5k ohm bridging.
-
· Noise: unity gain (better than -100dbU) Max gain +75dB
(better than -70dbU).
-
· EIN: better than -120dB.
-
· Freq response: +/- 0.5dB 20Hz-20kHz; -3dB at 50kHz.
-
· Distortion: 0.005% at 1kHz at +20dBu output.
-
· Max power consumption: 170mA(+16V); 100mA(-16V).
Please note that front panel text details are subject to change
upon final release. Release date - Mid of September.
Dimensions : 38x133x145mm Warranty: 2 years
https://wesaudio.com/product/_phoebe/
